Form factor 3U 19” rack mount
Drives supported • Up to 16 3.5” drives
• 6/12 Gb SAS, 6 Gb SATA HDD and SSD
• Supports any mix of SAS and SATA drives simultaneously in the same
enclosure
IO Ports
per IO module
• Two 12G SFF-8644 mini-SAS connector per controller for JBOD
expansion.
Power Supplies CRPS 550W; Efciency 80PLUS Certied Redundant Power Supply
Voltage AC: 100-240VAC; DC: 180-320VDC Auto-Ranging
Current
(Maximum)
< 8A@100-240VAC@full load; < 8A@180-320VDC@full load
Power Conversion
Efciency
>80% @ 110V (>20% load), >80% @ 240V (>20% load)
Dimensions
(Height, Width, Depth)
131mm x 446.7mm x 507mm (5.2” x 17.6” x 19.96”)
Weight
Single controller models Dual controller models
(w/o drives)
(w drives)
17.72 kg
28,92 kg
19.8 kg
31 kg
Vess J3600 JBOD models
5
Promise Technology
Introduction
