Drive slot numbering on Vess R3600 (Vess J3600 numbering is idencal)
Caution
TheVessR3600SeriesandVessJ3600JBODsupportdiskdrive
hot-swapping.Toavoidhandcontactwithanelectricalhazard,
donotremovemorethanonedrivecarrieratime.
Drive Slot Numbering
You can install any suitable disk drive into any slot in the enclosure. The diagrams below shows how drive slots
arenumberedontheVessR3600SeriesandVessJ3600models.SlotnumberingisreectedintheWebPAM
PROe and CLI user interfaces.
Be sure to install all of the drive carriers into the Vess R3600 and Vess J3600 enclosure to ensure proper
airow,evenifyoudonotpopulateallthecarrierswithphysicaldrives.
