Making iSCSI iSNS Settings
To make iSNS settings:
1. Click the Device tab.
2. Click the iSCSI Management icon.
3. Click the iSNS tab.
4. Click on a portal to select it.
5. Click the Modify button.
6. Make settings changes are required:
• Enable (check to enable)
• Server Port (1-65535)
• Server IP
• IO Portal ID
7. Click the Submit button.
Viewing a List of iSCSI CHAPs
To view a list of iSCSI CHAPs:
1. Click the Device tab.
2. Click the iSCSI Management icon.
3. Click the CHAP tab.
CHAP information includes:
• ID – ID number of the CHAP
• Type – Peer or local
Peer is one-way or uni-directional.
Local is two-way or bi-directional.
• Name – User assigned name of the CHAP
