Promise Technology Vess R3600 Series User Manual

Vess R3600 with Vess J3600sSD JBOD expansion
Duel Controller Expansion with Vess R3600
To setup a redundant JBOD cascading connection:
1. Use the SFF-8644 external SAS cable supplied with the Vess J3600sSD to connect the SAS port in left
controller of the Vess R3600sD to a SAS port 1 of left controller on the uppermost Vess J3600sSD in the
rack.
2. Connect SAS Port 2 of the left controller on the same Vess J3600sSD to the SAS Port 1 of the left
controller on the next Vess J3600sSD in the stack.
3. In the same manner, connect the SAS ports of the right controllers on the Vess R3600sD to the right
controllers of the Vess J3600sSD in the stack.
4. Connect the remaining Vess J3600sSD enclosures in the same manner.
32
