Communications Protocol CubiScan 125 Command Set
CubiScan 125 93
* This field may contain underscores, dashes, or tildes indicating an
under, unstable, or over error condition, respectively. Leading
spaces (20h) will be used when the actual data does not fill the
entire field.
34 1 Comma Alpha (,) 2Ch
35 1 Weight Identifier Alpha (K) 4Bh
36 6 Weight Numeric 00.000 - 99.999*
42 1 Comma Alpha (,) 2Ch
43 1 Dim. Wgt. Identifier Alpha (D) 44h
44 6 Dim. Weight Numeric 000.00-999.99*
50 2 Wgt./Dim.Wgt Unit Alpha lb/kg
52 1 Comma Alpha (,) 2Ch
53 1 Factor Identifier Alpha (F) 46h
54 4 Factor Numeric 0000-9999
58 1 Comma Alpha (,) 2Ch
59 1 Domestic/Int'l. Unit Alpha (D/I) 44h or 49h
60 1 End of Text Control (ETX) 03h
61 1 Carriage Return Control (CR) 0Dh
62 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 6Dh
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 CubiScan/Host Originated Alpha (C/H) 43h or 48h
51
Corner Sensor / Measure /
Zero Error
Alpha (C/M/Z)
43h or 4Dh
or 5Ah
6 1 End of Text Control (ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
