Communications Protocol TCP/IP Communications Setup Command Set
CubiScan 125 111
Read Gateway Address
This command is used to read the current gateway address setting
from the CubiScan 125.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Gateway Address Command Alpha (G) 47h
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Gateway Address Command Alpha (G) 47h
4 1 Acknowledge Alpha (A) 41h
5
7-15
or n
IP Address Alpha
(0.0.0.0) to
(255.255.255.255)
5+n 1 End of Text Control (ETX) 03h
6+n 1 Carriage Return Control (CR) 0Dh
7+n 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
Pos Len Description Type Range ASCII
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Gateway Address Command Alpha (G) 47h
4 1 Neg. Acknowledge Alpha (N) 4Eh
5 1 End of Text Control (ETX) 03h
