CubiScan 125 Command Set Communications Protocol
92 CubiScan 125
* This field may contain underscores, dashes, or tildes indicating an
under, unstable, or over error condition, respectively. Leading
spaces (20h) will be used when the actual data does not fill the
entire field.
Gate Measure
The CubiScan 125 will automatically send measurement data upon
completion of a gate measurement.
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Pos Len Description Type Range ASCII
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (m) 6Dh
3 1 Acknowledge Alpha (A) 41h
4 1 CubiScan/Host Originated Alpha (C/H) 43h or 48h
5 6 City Code Alpha 000000-ZZZZZZ
11 1 Comma Alpha (,) 2Ch
12 1 Length Identifier Alpha (L) 4C
13 5 Length Numeric 00.00 - 99.99*
18 1 Comma Alpha (,) 2Ch
19 1 Width Identifier Alpha (W) 57h
20 5 Width Numeric 00.00 - 99.99*
25 1 Comma Alpha (,) 2Ch
26 1 Height Identifier Alpha (H) 48h
27 5 Height Numeric 00.00 - 99.99*
32 2 Dimension Unit Alpha in/cm
