CubiScan 125 Command Set Communications Protocol
86 CubiScan 125
Dimension Calibration
This function is required when one of the sensors is replaced or
moved, when a new controller is installed, or for routine calibration.
This command causes the CubiScan 125 to reply with a dimension
calibration code each time it is issued. This command must be
issued FIVE times to complete sensor calibration. Dimension cali-
bration codes are defined below.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Dim.Calibration Alpha (D) 44h
3 1 End of Text Control (ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
5 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Calibration Alpha (D) 44h
3 1 Acknowledge Alpha (A) 41h
4 2 Identifier Numeric (00-99)
6 1 End of Text Control (ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Calibration Alpha (D) 44h
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
