CubiScan 125 Command Set Communications Protocol
94 CubiScan 125
Scale Calibration
This function is required when the load cell is replaced, when a new
controller is installed, or for routine calibration. This command
causes the CubiScan 125 to reply with a scale calibration code. This
command must be issued THREE times to complete scale calibra-
tion. Scale calibration codes are defined below.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 6 Test Weight Value Numeric 050.00-100.00
9 1 End of Text Control (ETX) 03h
10 1 Carriage Return Control (CR) 0Dh
11 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 1 Acknowledge Alpha (A) 41h
4 2 Identifier Numeric (00-99)
6 1 End of Text Control (ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Scale Calibration Alpha (S) 53h
3 1 Neg. Acknowledge Alpha (N) 4Eh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
