Setup Assembling the CubiScan 125
CubiScan 125 9
the back and sides of the CubiScan 125. Do not rest objects
against or set objects on the CubiScan 125 when not in use.
• If a computer is used, place it as close to the CubiScan 125 as
possible. The operator needs to use the keyboard or mouse on the
computer while cubing and weighing packages using the Cubi-
Scan 125.
• Orient the CubiScan 125 so the touch screen faces the operator.
Assembling the CubiScan 125
The CubiScan 125 is almost completely assembled when shipped.
You only need to attach the top sensor support and route the sensor
cable. Take the following steps.
1. Place the base assembly of the CubiScan 125 on a stable sur-
face. (An optional cart, custom-designed for the CubiScan 125,
is available from Quantronix.)
Do not remove the green foam shipping supports between the
scale base and platform or the wire tie that holds the measuring
gate in place; they will help prevent damage to the load cells
and gate while you are assembling the CubiScan 125.
