Communications Protocol CubiScan 125 Command Set
CubiScan 125 87
Dimension Calibration Code Descriptions:
DA01 Clear the CubiScan
DA02 Place 12" Target facing LEFT
DA03 Place 12" Target facing RIGHT
DA04 Place 12" Target facing UP
DA05 Dimension Calibration Complete
Dimension Units
This command is used to set the dimension units to either English
(inches) or metric (centimeters) mode.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Unit Command Alpha (") 22h
3 1 English or Metric Alpha (E/M) 45h or 4Dh
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Unit Command Alpha (") 22h
3 1 Acknowledge Alpha (A) 41h
4 1 End of Text Control (ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Dim. Unit Command Alpha (") 22h
