Connecting to a Computer or Network Setup
22 CubiScan 125
• Connect the CubiScan 125 to a PC through the USB port on the
back of the controller box. You will need to load the USB driver
supplied by Quantronix to use this port. Follow the instructions
on page 24 to load the driver.
• Operate the CubiScan 125 without a computer using the touch
screen. Refer to “Cubing and Weighing Using the Touch Screen”
on page 38 for information.
NOTE
If you are not going to connect the CubiScan 125 to a computer or
network, proceed to page 32 for information on connecting power.
Connecting to a Computer (Optional)
To connect the CubiScan 125 to a computer, do the following.
1. Place the computer close to the CubiScan 125. (Refer to “Place-
ment” on page 8 for information.)
2. Route the RS-232 serial communications cable (supplied)
through an opening in the base so it cannot be crushed, bent, or
pulled loose. Make sure that the cable does not interfere with
the scale.
3. The CubiScan 125 controller is located just behind the touch
screen at the front of the base. Connect one end of the serial
cable to the computer serial connector on the back of the Cubi-
Scan 125 controller, or connect the USB cable to the USB port
(see note below), as shown below.
☞
CAUTION
Disconnect power from the CubiScan 125 and the computer
before connecting them.
