Communications Protocol TCP/IP Communications Setup Command Set
CubiScan 125 105
Set IP Address
This command is used to set the CubiScan 125 IP address. The IP
address, or Internet address, is usually expressed in “dot” notation;
for example, “121.43.6.234.” The first three groups of numbers
(e.g., 121.43.6) are usually specific to the network to which you are
connecting. The last number (e.g., 234) is specific to a particular
CubiScan 125. Consult your network administrator to obtain an
available IP address.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
3 1 IP Address Command Alpha (I) 49h
4
7-15
or n
IP Address Alpha
(0.0.0.0) to
(255.255.255.255)
4+n 1 End of Text Control (ETX) 03h
5+n 1 Carriage Return Control (CR) 0Dh
6+n 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
3 1 IP Address Command Alpha (I) 49h
4 1 Acknowledge Alpha (A) 41h
5 1 End of Text Control (ETX) 03h
6 1 Carriage Return Control (CR) 0Dh
7 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
