Quantronix CubiScan 125 User Manual

Setup Assembling the CubiScan 125
CubiScan 125 15
7. Place the sensor cable cover over the wire as shown below,
aligning the screws on the side of the sensor cover with the slots
in the top support. Slide the sensor cover into place, and tighten
the screws.
Figure 9
Attaching the Sensor Cable Cover
