Removing the Controller Box Maintenance
76 CubiScan 125
• To remove a serial cable, loosen the screws (with a screw-
driver if necessary), and pull the cable connector out using
even pressure.
6. Remove the four Allen head screws on the corners of the con-
troller box mounting plate (see Figure 55 above) using the 1/8"
Allen wrench. The touch screen is in the center of the mounting
plate, and the mounting plate is attached to the front of the
CubiScan 125 base.
7. Verify that all cables have been removed from the controller
box, then pull the box out from the front.
