33.9SeaTalkaccessories

SeaTalkcablesandaccessoriesforusewith

compatibleproducts.

DescriptionPartNoNotes

3–waySeaTalk

junctionbox

D244

1m(3.28ft)

SeaTalkextension

cable

D284

3m(9.8ft)SeaTalk

extensioncable

D285

5m(16.4ft)

SeaTalkextension

cable

D286

9m(29.5ft)

SeaTalkextension

cable

D287

12m(39.4ft)

SeaTalkextension

cable

E25051

20m(65.6ft)

SeaTalkextension

cable

D288

33.10e9ande12Videocables

Thefollowingvideocableisrequiredforthevideoin

/outconnectoronthee95/e97/e125/e127variant

multifunctiondisplays.

PartnumberDescriptionNotes

R70003

5m(16.4ft.)Video

cablefore9and

e12(1xvideoin

and1xvideoout

VGA)

Sparesandaccessories

445
