Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
165
Edition: July 1, 2005 3646/110 --233.DOC010302
Seq.
no.
Comments, NotesIndications
5 Corr = Corrected course (course taking SEC into account).
12345678
OPEN
Switch B37 (DIP switch)
B38
4x
B39
The automatic Speed Error
Correction function is defective.
Speed or/and position faulty.
6 _roh = Rough course (course without SEC).
12345678
OPEN
Switch B37 (DIP switch)
B39
B38
5x
Identical with Seq.no. 1
