Raytheon Anschütz STD 22 Compact GYRO COMPASS Installation And Service Manual

Compass
STD 22
Installation and Service manual
Compass STD 22
Compass STD 22 Compact
11
Edition: Feb. 17, 2006 3646/110 --233.DOC010302
24VDC
18--36 V.d.c.
AC/DC converter
121--062
Option:
or
Distribution Unit
138--118
Operator Unit
130--613
CAN bus
8x Heading (12x) (course bus or NMEA)
3x Step
1x rate of turn
1x RS232 for printer
STD 22 GGMS Gyro Compass System
*
Typ 110--233 *(GGMS = Gyro/Gyro/Magnet/Satellite Compass)
see manual no.:3648
see manual no.: 3647
Inputs:
-- Pulse Log -- Pulse Log Direction
Pulse Log Direction Pulse Log
Outputs:
Distribution Unit:
-- 8x Heading RMG course bus or NMEA -- 3x Step (6 steps/degree), 24/35VDC, max. 10W -- 1x RS232 serial interface for printer -- 1x rate of turn +/-- 10V for 30/100/300 degrees/min -- 12x Status (potential free)
Compass
STD 22
110 --233
CAN bus
Processor
Unit
114 --001
Antenna unit
114 --002
Magnetic sonde
Compass
STD 22
110 --233
115--230VAC 50/60Hz
108--010
*
*The number of necessary
AC/DC converters depends on the neces- sary max. power of all supplied devices
see manual no.:3717
