(18) LIN/UART Mode Status Register (LMSTn)
Address: F06D1H
7 6 5 4 3 2 1 0
— — — — — — OMM1 OMM0
Value after reset:
0 0 0 0 0 0 0 0
Bit Symbol Bit Name Function R/W
0 OMM0 LIN Reset Status Monitor 0: The module is in LIN reset mode.
1: The module is not in LIN reset mode.
R
1 OMM1 LIN Mode Status Monitor 0: The module is in LIN wake-up mode.
1: The module is in LIN operation mode.
R
7 to 2 — Reserved These bits are always read as 0. The write value should always
be 0.
R/W
OMM0 bit (LIN reset status monitor)
OMM1 bit (LIN mode status monitor)
The OMM0 and OMM1 bits indicate the current operation mode.
