RL78/F13, F14 CHAPTER 24 RESET FUNCTION
R01UH0368EJ0210 Rev.2.10 1548
Dec 10, 2015
Table 24-2. States of Hardware After Acceptance of a Reset (2/4)
Hardware After Acceptance of a Reset
Note 1
External interrupt falling edge enable register 0 (EGN0) 00H
External interrupt rising edge enable register 1 (EGP1) 00H
External interrupt falling edge enable register 1 (EGN0) 00H
Serial data register 10 (SDR10) 0000H
Serial data register 11 (SDR11) 0000H
IICA shift register 0 (IICA0) 00H
IICA status register 0 (IICS0) 00H
IICA flag register 0 (IICF0) 00H
16-bit watch error correction register (SUBCUDW) 0000H
Timer RD general register C0 (TRDGRC0) FFFFH
Note 3
Timer RD general register D0 (TRDGRD0) FFFFH
Note 3
Timer RD general register C1 (TRDGRC1) FFFFH
Note 3
Timer RD general register D1 (TRDGRD1) FFFFH
Note 3
Timer data register 02 (TDR02) 0000H
Timer data register 03 (TDR03/L/H) 00H
Timer data register 04 (TDR04) 0000H
Timer data register 05 (TDR05) 0000H
Timer data register 06 (TDR06) 0000H
Timer data register 07 (TDR07) 0000H
Timer data register 10 (TDR10) 0000H
Timer data register 11 (TDR11/L/H) 00H
Timer data register 12 (TDR12) 0000H
Timer data register 13 (TDR13/L/H) 00H
Timer data register 14 (TDR14) 0000H
Timer data register 16 (TDR16) 0000H
Timer data register 17 (TDR17) 0000H
Second count register (SEC)
00H
Minute count register (MIN)
00H
Hour count register (HOUR)
12H
Note 4
Week count register (WEEK)
00H
Day count register (DAY)
01H
Month count register (MONTH)
01H
Year count register (YEAR)
00H
Watch error correction register (SUBCUD)
00H
Alarm minute register (ALARMWM)
00H
Alarm hour register (ALARMWH)
12H
Alarm week register ALARMWW)
00H
Real-time clock control register 0 (RTCC0) 00H
Real-time clock control register 1 (RTCC1) 00H
Clock operation mode control register (CMC) 00H
Clock operation status control register (CSC) C0H
Oscillation stabilization time counter status register (OSTC) 00H
Oscillation stabilization time select register (OSTS) 07H
System clock control register (CKC) 00H
Clock output select register 0 (CKS0) 00H
Reset control flag register (RESF) Undefined
Note 5
Voltage detection register (LVIM) 00H
Note 5
Voltage detection level register (LVIS) 00H/01H/81H
Note 6
Watchdog timer enable register (WDTE) 1AH/9AH
Note 7
CRC input register (CRCIN) 00H
Interrupt request flag register 2 (IF2/L/H) 00H
(Notes and Remark are given below Table 24-2, States of Hardware After Acceptance of a Reset (4/4).)
To Next Page
