RL78/F13, F14 CHAPTER 24 RESET FUNCTION
R01UH0368EJ0210 Rev.2.10 1549
Dec 10, 2015
Table 24-2. States of Hardware After Acceptance of a Reset (3/4)
Hardware After Acceptance of a Reset
Note 1
Interrupt request flag register 3L (IF3L) 00H
Interrupt mask flag register 2 (MK2/L/H) FFH
Interrupt mask flag register 3 (MK3L) FFH
Priority specification flag register 02 (PR02/L/H) FFH
Priority specification flag register 03 (PR03L) FFH
Priority specification flag register 12 (PR12/L/H) FFH
Priority specification flag register 13 (PR13L) FFH
Interrupt request flag register 0 (IF0/L/H) 00H
Interrupt request flag register 1 (IF1/L/H) 00H
Interrupt mask flag register 0 (MK0/L/H) FFH
Interrupt mask flag register 1 (MK1/L/H) FFH
Priority specification flag register 00 (PR00/L/H) FFH
Priority specification flag register 01 (PR01/L/H) FFH
Priority specification flag register 10 (PR10/L/H) FFH
Priority specification flag register 11 (PR11/L/H) FFH
Multiply and accumulation register (L) (MACRL) 0000H
Multiply and accumulation register (H) (MACRH) 0000H
Processor mode control register (PMC) 00H
Comparator control register (CMPCTL) 00H
Comparator input and output switching register (CMPSEL) 00H
Comparator output monitor register (CMPMON) 00H
CAN clock select register (CANCKSEL) 00H
LIN clock select register (LINCKSEL) 00H
Clock select register (CKSEL) 00H
PLL control register (PLLCTL) 00H
PLL status register (PLLSTS) 00H
POR/CLM reset confirmation register (POCRES) Undefined
High-speed DTC control register 0 (HDTCCR0) 00H
High-speed DTC transfer count register 0 (HDTCCT0) 00H
High-speed DTC transfer count reload register 0 (HDTRLD0) 00H
High-speed DTC source address register 0 (HDTSAR0) 0000H
High-speed DTC destination address register 0 (HDTDAR0) 0000H
High-speed DTC control register 1 (HDTCCR1) 00H
High-speed DTC transfer count register 1 (HDTCCT1) 00H
High-speed DTC transfer count reload register 1 (HDTRLD1) 00H
High-speed DTC source address register 1 (HDTSAR1) 0000H
High-speed DTC destination address register 1 (HDTDAR1) 0000H
DTC base address register (DTCBAR) FDH
High-speed DTC channel select register 0 (SELHS0) 3FH
High-speed DTC channel select register 1 (SELHS1) 3FH
DTC activation enable register 0 (DTCEN0) 00H
DTC activation enable register 1 (DTCEN1) 00H
DTC activation enable register 2 (DTCEN2) 00H
DTC activation enable register 3 (DTCEN3) 00H
DTC activation enable register 4 (DTCEN4) 00H
DTC activation enable register 5 (DTCEN5)
Note 8
00H
CRC operation mode control register (CRCMD) 00H
CRC data register (CRCD) 0000H
LIN wakeup baud rate select register (LWBR0/LWBR1) 00H
(Notes and Remark are given below Table 24-2, States of Hardware After Acceptance of a Reset (4/4).)
