RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 155
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (4/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F0152H Serial channel start register 1 SS1L SS1 R/W    0000H
F0153H – – –
F0154H Serial channel stop register 1 ST1L ST1 R/W    0000H
F0155H – – –
F0156H Serial clock select register 1 SPS1L SPS1 R/W –   0000H
F0157H – – –
F0158H Serial output register 1 SO1 R/W – –  0303H
F0159H
F015AH Serial output enable register 1 SOE1L SOE1 R/W    0000H
F015BH – – –
F0160H Serial output level register 1 SOL1L SOL1 R/W –   0000H
F0161H – – –
F0162H Serial slave select enable register 1 SSE1L SSE1 R/W –   0000H
F0163H – – –
F0180H Timer counter register 00 TCR00 R – –  FFFFH
F0181H
F0182H Timer counter register 01 TCR01 R – –  FFFFH
F0183H
F0184H Timer counter register 02 TCR02 R – –  FFFFH
F0185H
F0186H Timer counter register 03 TCR03 R – –  FFFFH
F0187H
F0188H Timer counter register 04 TCR04 R – –  FFFFH
F0189H
F018AH Timer counter register 05 TCR05 R – –  FFFFH
F018BH
F018CH Timer counter register 06 TCR06 R – –  FFFFH
F018DH
F018EH Timer counter register 07 TCR07 R – –  FFFFH
F018FH
F0190H Timer mode register 00 TMR00 R/W – –  0000H
F0191H
F0192H Timer mode register 01 TMR01 R/W – –  0000H
F0193H
F0194H Timer mode register 02 TMR02 R/W – –  0000H
F0195H
F0196H Timer mode register 03 TMR03 R/W – –  0000H
F0197H
F0198H Timer mode register 04 TMR04 R/W – –  0000H
F0199H
F019AH Timer mode register 05 TMR05 R/W – –  0000H
F019BH
