RL78/F13, F14 CHAPTER 3 CPU ARCHITECTURE
R01UH0368EJ0210 Rev.2.10 156
Dec 10, 2015
Table 3-6. Extended SFR (2nd SFR) List (5/32)
Address Special Function Register (2nd SFR) Name Symbol R/W Manipulable Bit Range After reset
1-bit 8-bit 16-bit
F019CH Timer mode register 06 TMR06 R/W – –  0000H
F019DH
F019EH Timer mode register 07 TMR07 R/W – –  0000H
F019FH
F01A0H Timer status register 00 TSR00L TSR00 R –   0000H
F01A1H – – –
F01A2H Timer status register 01 TSR01L TSR01 R –   0000H
F01A3H – – –
F01A4H Timer status register 02 TSR02L TSR02 R –   0000H
F01A5H – – –
F01A6H Timer status register 03 TSR03L TSR03 R –   0000H
F01A7H – – –
F01A8H Timer status register 04 TSR04L TSR04 R –   0000H
F01A9H – – –
F01AAH Timer status register 05 TSR05L TSR05 R –   0000H
F01ABH – – –
F01ACH Timer status register 06 TSR06L TSR06 R –   0000H
F01ADH – – –
F01AEH Timer status register 07 TSR07L TSR07 R –   0000H
F01AFH – – –
F01B0H Timer channel enable status register 0 TE0L TE0 R    0000H
F01B1H – – –
F01B2H Timer channel start register 0 TS0L TS0 R/W    0000H
F01B3H – – –
F01B4H Timer channel stop register 0 TT0L TT0 R/W    0000H
F01B5H – – –
F01B6H Timer clock select register 0 TPS0 R/W – –  0000H
F01B7H
F01B8H Timer output register 0 TO0L TO0 R/W –   0000H
F01B9H – – –
F01BAH Timer output enable register 0 TOE0L TOE0 R/W    0000H
F01BBH – – –
F01BCH Timer output level register 0 TOL0L TOL0 R/W –   0000H
F01BDH – – –
F01BEH Timer output mode register 0 TOM0L TOM0 R/W –   0000H
F01BFH – – –
F01C0H Timer counter register 10 TCR10 R – –  FFFFH
F01C1H
F01C2H Timer counter register 11 TCR11 R – –  FFFFH
F01C3H
F01C4H Timer counter register 12 TCR12 R – –  FFFFH
F01C5H
