RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 212

Dec 10, 2015

Figures 4-5 to 4-12 show block diagrams of port 1 for 100-pin products.

Figure 4-5. Block Diagram of P10

P10/TI13/TO13

TRJO0/SCK10/

SCL10/LTXD1/

CTXD0

PORT

PU10

P10

P-ch

PU1

PM1

POM10

POM1

POM

PM10

CMOS

(Schmitt3)

TTL

PIM1

PIM10

PIM

PITHL1

PITHL10

PITHL

CMOS

(Schmitt1)

PMS

PMS0

SCK10/SCL10

/LTXD1/CTXD0

TO13/TRJO0

Internal bus

Selector

Output latch

Alternate function

P1: Port register 1

PU1: Pull-up resistor option register 1

PM1: Port mode register 1

PIM1: Port input mode register 1

POM1: Port output mode register 1

PMS: Port mode select register

PITHL1: Port input threshold control register 1

RD: Read signal

WRxx: Write signal
