RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 213

Dec 10, 2015

Figure 4-6. Block Diagram of P11

P11/TI12/TO12/

SI10/SDA10/RXD1

LRXD1/CRXD0/

(TRDIOB0)

PORT

PU11

P11

P-ch

PU1

PM1

POM11

POM1

POM

PM11

CMOS

(Schmitt3)

TTL

PIM1

PIM11

PIM

PITHL1

PITHL11

PITHL

CMOS

(Schmitt1)

PMS

PMS0

Alternate function

SDA10

Alternate function

TO12/(TRDIOB0)

Alternate function

Internal bus

Selector

Output latch

P1: Port register 1

PU1: Pull-up resistor option register 1

PM1: Port mode register 1

PIM1: Port input mode register 1

POM1: Port output mode register 1

PMS: Port mode select register

PITHL1: Port input threshold control register 1

RD: Read signal

WRxx: Write signal
