RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 216

Dec 10, 2015

Figure 4-9. Block Diagram of P14

P14/TI06/TO06/

TRDIOC0/SCK01

SCL01/LRXD0

PORT

PU14

P14

P-ch

PU1

PM1

POM14

POM1

POM

PM14

CMOS

(Schmitt3)

TTL

PIM1

PIM14

PIM

PITHL1

PITHL14

PITHL

CMOS

(Schmitt1)

PMS

PMS0

Alternate function

TO06/TRDIOC0

Alternate function

SCK01/SCL01

Alternate function

Internal bus

Selector

Output latch

P1: Port register 1

PU1: Pull-up resistor option register 1

PM1: Port mode register 1

PIM1: Port input mode register 1

POM1: Port output mode register 1

PMS: Port mode select register

PITHL1: Port input threshold control register 1

RD: Read signal

WRxx: Write signal
