RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS

R01UH0368EJ0210 Rev.2.10 304

Dec 10, 2015

Figure 4-71. Block Diagram of P152

P152/(SI11)

PORT

PU152

(SI11)

P152

PM152

P-ch

PU15

PM15

P15

PMS

PMS0

PITHL15

PITHL152

PITHL

CMOS

(Schmitt3)

CMOS

(Schmitt1)

Internal bus

Output latch

Alternate function

Selector

P15: Port register 15

PU15: Pull-up resistor option register 15

PM15: Port mode register 15

PMS: Port mode select register

PITHL15: Port input threshold control register 15

RD: Read signal

WRxx: Write signal
