RL78/F13, F14 CHAPTER 4 PORT FUNCTIONS
R01UH0368EJ0210 Rev.2.10 335
Dec 10, 2015
Notes 1. Products of Groups C to E only
2. Products of Groups C and D only
3. Group E products only
4. Products of Groups B to E only
5. Products of Groups B to D only
6. The simplified IIC function (SDA and SCL) cannot be used when PIOR is 1.
Cautions 1. The 30- and 20-pin products do not have the PIOR4 register.
2. Set the bit the use of which is prohibited to 0.
