RL78/F13, F14 CHAPTER 5 CLOCK GENERATOR
R01UH0368EJ0210 Rev.2.10 415
Dec 10, 2015
Table 5-3. Changing CPU Clock (3/7)
CPU Clock Conditions before Change Processing after Change
Before Change After Change
External main system
clock
High-speed on-chip
oscillator clock
The high-speed on-chip oscillator starts
oscillation.
 HIOSTOP = 0
The external main system clock
input can be disabled.
(MSTOP = 1)
X1 clock
Prohibited to change. (To change the CPU
clock, clear the settings first and then reset the
settings.)

XT1 clock
XT1 oscillation is stable, and the subsystem
clock is selected as the subsystem/low-speed
on-chip oscillator select clock.
 OSCSELS = 1, EXCLKS = 0, XTSTOP = 0
 SELLOSC = 0
 After elapse of oscillation stabilization time
The external main system clock
input can be disabled.
(MSTOP = 1)
External subsystem
clock
External clock input from the EXCLKS pin is
enabled, and the subsystem clock is selected
as the subsystem/low-speed on-chip oscillator
select clock.
 OSCSELS = 1, EXCLKS = 1, XTSTOP = 0
 SELLOSC = 0
Low-speed on-chip
oscillator clock
The low-speed on-chip oscillator starts
oscillation, and the low-speed on-chip oscillator
clock is selected as the subsystem/low-speed
on-chip oscillator select clock.
 OSCSELS = 1, SELLOSC = 1
PLL clock PLL oscillation is stable.
 LOCK = 1, PLLON = 1
The external main system clock
cannot be stopped because it is
the PLL input clock.
Remark For details about the register flag settings for stopping the target clock during the processing after change and
conditions before the clock is stopped, see 5.6.9 Conditions Before Clock Oscillation Is Stopped.
