RL78/F13, F14 CHAPTER 2 PIN FUNCTIONS
R01UH0368EJ0210 Rev.2.10 61
Dec 10, 2015
Table 2-3. List of RL78/F13 (CAN and LIN incorporated) Pins Other than Port Pins (2/4)
Pin
Function
I/O Function Pin Count
80-pin 64-pin 48-pin 32-pin 30-pin
TO02 Output 16-bit timer 02 output     
TO03 Output 16-bit timer 03 output (8-bit mode available)     
TO04 Output 16-bit timer 04 output     
TO05 Output 16-bit timer 05 output     
TO06 Output 16-bit timer 06 output     
TO07 Output 16-bit timer 07 output     
TO10 Output 16-bit timer 10 output     
TO11 Output 16-bit timer 11 output (8-bit mode available)     
TO12 Output 16-bit timer 12 output     
TO13 Output 16-bit timer 13 output (8-bit mode available)     
TRJIO0 I/O Timer RJ input/output     
TRJO0 Output Timer RJ output     
TRDCLK0 Input Timer RD external clock input     
TRDIOA0 I/O Timer RD0 input/output     
TRDIOB0 I/O     
TRDIOC0 I/O     
TRDIOD0 I/O     
TRDIOA1 I/O Timer RD1 input/output     
TRDIOB1 I/O     
TRDIOC1 I/O     
TRDIOD1 I/O     
RXD0 Input Serial data input to UART0     
RXD1 Input Serial data input to UART1     
TXD0 Output Serial data output from UART0     
TXD1 Output Serial data output from UART1     
SCLA0 I/O Clock input/output for IICA0     
SCL00 Output Clock output from simplified I
2
C     
SCL01 Output     
SCL10 Output     
SCL11 Output     
SDAA0 I/O Serial data input/output for IICA0     
SDA00 I/O Serial data input/output for simplified I
2
C     
SDA01 I/O     
SDA10 I/O     
SDA11 I/O     
SCK00 I/O Clock input/output for CSI00     
SCK01 I/O Clock input/output for CSI01     
SCK10 I/O Clock input/output for CSI10     
SCK11 I/O Clock input/output for CSI11     
SI00 Input Serial data input to CSI00     
SI01 Input Serial data input to CSI01     
SI10 Input Serial data input to CSI10     
