Ricoh Aficio SP C232SF Service Manual

Service Menu
SM Appendix 4-15 M018/M019
Appendix:
SP Mode
Tables
Menu List
Fax Test
On Hook Executes the on hook test.
Off-Hook Test
Off Hook Executes the off hook test
CED Test Executes the CED test.
CNG Test 1100 Hz Executes the CNG test
ANSam Executes the ANSam test.
Ring Tone Test Executes the ring tone test.
Tone [0] to [9] Executes the DTMF tone 0 to 9 test.
Tone [*] Executes the DTMF tone * test.
Tone [#] Executes the DTMF tone # test.
DTMF Test
Tone Stop Executes the Stop DTMF tone test.
[V34] 33600 bps Generates the [V34] 33600 bps signal.
[V34] 28800 bps Generates the [V34] 28800 bps signal.
[V17] 14400 bps Generates the [V17] 14400 bps signal.
[V17] 12000 bps Generates the [V17] 12000 bps signal.
[V17] 9600 bps Generates the [V17] 9600 bps signal.
[V17] 7200 bps Generates the [V17] 7200 bps signal.
[V29] 9600 bps Generates the [V29] 9600 bps signal.
[V29] 7200 bps Generates the [V29] 7200 bps signal.
[V27] 4800 bps Generates the [V27] 4800 bps signal.
[V27] 2400 bps Generates the [V27] 2400 bps signal.
[V21] 300 bps Generates the [V21] 300 bps signal.
Modem Test
Signal Stop Generates the Stop signal.
Rev. 07/02/2009
