Electrical Components
M018/M019 4-52 SM
4.11.8 PSU
1. Operation panel ( p.4-4)
2. Rear cover ( p.4-3)
3. Left cover ( p.4-5)
4. Drive unit ( p.4-13 "Black AIO Motor")
5. LSU fan base ( p.4-49 "LSU Fan Motor")
6. PSU guide [A] (
x 3)
7. Power cord bracket [B] (
x 2)
8. Ground cable [C] (
x 1)
9. Power switch assembly [D] (washer screw [a] x 2,
x 1, x 2)
