Overview
SM 7 G849
Paper Feed
Unit TK1010
(G849)
2. DETAILED SECTION DESCRIPTIONS
2.1 OVERVIEW
2.1.1 COMPONENT LAYOUT
1. Side Fence
2. Paper End Sensor
3. Paper Feed Roller
4. Relay Sensor
5. Relay Roller
6. Friction Pad
7. Paper Height Lever
8. Bottom Plate
9. Rear Fence
