Paper Exit
M018/M019 4-40 SM
4.10 PAPER EXIT
4.10.1 PAPER EXIT ROLLER
1. Operation panel ( p.4-4)
2. Remove the bushing [A] (
x 1)
3. Move the bushing [B] to the left side (
x 1).
4. Paper exit roller [B]
5. Remove the four exit guides [D], gear [E] ( x 1) and bushing [F].
