AIO Cartridge
M018/M019 4-14 SM
5. Harness guide [D] ( x 4)
6. Interlock switch base ( Interlock Switches)
7. Controller bracket ( p.4-43 "Controller Board")
8. Disconnect the connector (CN305) on the EGB.
9. LSU fan motor base [E] ( x 2, x 1)
10. Drive unit [F] (
x 4)
