Image Transfer
SM 4-25 M018/M019
Replacement
&
Adjustment
6. Remove the mylar fixing three hooks of the waste toner bottle set sensor.
7. Waste toner bottle set sensor [C] (hooks, x 1)
When reinstalling the waste toner bottle set sensor, connect it to the white
connector of the harness.
http://www.manuals4you.com
