Ricoh CH-C1 - RTB 71: Troubleshooting for Margin adjustment

Technical Bulletin PAGE: 1/2
Model: Model CH-C1 (Office/Pro)
Date: 05-Feb-14
No.: RD135071
Subject: Troubleshooting for Margin adjustment
Prepared by: Ryuuta Chino
From: 1st Tech Service Sect. PP Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Product Safety
Part information
Electrical
Transmit/receive
Other ( )
Action required
Service manual revision
Retrofit information
Tier 2
Service Manual Revision
Add the following, which was missing from the manual.
How to adjust
1. Adjust the margins using the following SPs.
Leading edge margin adjustment
Pro/Office
SP No.
SP Name
Value
Pro/Office
SP2-122-201 to 254
[Erase Margin Adj Leading
Edge] (for each paper
type/thickness)
-3 to 6mm
Pro
SP2-122-001 to 100
[Erase Margin Adj Leading
Edge] (for each custom
paper)
-3 to 6mm
Pro/Office
IMSS setting No.
IMSS setting
Value
Pro
10
Adjust Erase Margin of
Leading Edge (for each
custom paper)
-3 to 6mm
Trailing edge margin adjustment
Pro/Office
SP No.
SP Name
Value
Pro/Office
SP2-123-201 to 254
[Erase Margin Adj Trailing
Edge] (for each paper
type/thickness)
-3 to 6mm
Pro
SP2-123-001 to 100
[Erase Margin Adj Trailing
Edge] (for each custom
paper)
-3 to 6mm
Pro/Office
IMSS setting No.
IMSS setting
Value
Pro
11
Adjust Erase Margin of
Trailing Edge (for each
custom paper)
-3 to 6mm
