Ricoh CH-C1 - RTB 114: Manual Correction: Drum motor (KCMY); Drum encoder sensor (KCMY) replacement

Technical Bulletin PAGE: 1/1
Model: CH-C1 Office/Pro
Date: 16-May-14
No.: RD135114
Service Manual Correction
Please add the following caution in the field service manual in this section:
4. Replacement and Adjustment > Motors and Sensors > Drum Motor (KCMY) /
Drum Encoder Sensor (KCMY) (Pg. 909)
Insert a sheet of paper as shown below when removing the drum motor in Step 6.
This will prevent the grease coated on the tip of the drum shaft from contacting
the ITB unit.
Subject: Manual Correction: Drum motor (KCMY) / Drum
encoder sensor (KCMY) replacement procedure
Prepared by: R. Chino
From: PP Tech Service Dept., 1st PP Tech Service Sect.
