Ricoh CH-C1 - RTB 33: Lubrication after replacement

Technical Bulletin PAGE: 1/2
Model: CH-C1
Date: 8-Oct-13
No.: RD135033
Subject: Lubrication after replacement
Prepared by: Takeshi Toriumi
From: 1st Tech Service Sect. MFP/P Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Product Safety
Part information
Electrical
Transmit/receive
Other ( )
Action required
Service manual revision
Retrofit information
Tier 2
Service Manual Revision
Replace “Lubrication after replacement” in Pg.630-631 with the following.
Lubrication after replacement
1. Turn on the machine.
2. Enter the SP mode and push the PM parts counter reset button in the PM
Parts display.
3. Replace the Image Transfer Belt.
4. Attach the toner hopper unit.
Note: Do not install the belt cleaning fan yet.
5. Attach the drawer unit cover.
6. Rotate the blade release lever to move the cleaning blade away from the ITB.
7. Pull out (open) the drawer unit.
8. Keep the drawer unit open, and then turn the machine main power ON.
Note: The automatic adjustment will not be performed when the machine is
turned ON, because the drawer unit is pulled out/opened.
8. Enter the SP mode and choose “SP2-696-001 (Force Apply Lubricant
Execute).
9. Push [Execute] on the operation panel and then push the drawer unit into the
machine.
Note: When the drawer unit is pushed into the machine, lubrication starts
automatically. This operation takes about 3 minutes to complete.
6. Turn the machine off when the lubrication finishes (the machine’s activity
stops).
7. Withdraw the drawer unit and rotate the blade release lever in order to make
the cleaning blade contact the ITB.
8. Re-install the belt cleaning fan (Screw x1).
9. Push the drawer unit into the machine.
