Technical Bulletin PAGE: 2/3
Model: Model CH-C1 (Office/Pro)
Date: 11-Mar-14
No.: RD135088
Solution
Do the following:
1. Increase the margins the leading/trailing edges (up to a maximum of 10mm).
See “Margin Adjustments”.
Note: If you adjust the margins without adjusting the image position, parts of the image may not
be printed. To adjust the image position, see Step 2 below.
2. If the symptom still occurs, try adjusting the position of the image at the same time.
Change the value in increments of -0.5mm, up to a maximum width of 10mm.
IMPORTANT: Before you make any registration adjustments, make sure that the
margin in the direction you will move the image is wide enough.
Subscan registration adjustments:
Pro or Office
SP No.
SP Name
Value
Pro/Office
SP1-001-004 to 111
Lead Edge Reg (for each
paper type)
±9.0
Pro
SP1-950-001 to 100
L-Edge Regist Adj (Front)
(for each custom paper)
±3.0
Pro
SP1-951-001 to 100
L-Edge Regist Adj (Rear)
(for each custom paper)
±3.0
Pro or Office
IMSS setting No.
IMSS setting
Value
Pro
6
Adjust Image Position of
Side 1 With Feed Direction
±3.0
Pro
7
Adjust Image Position of
Side 2 With Feed Direction
±3.0
3. If the symptom still occurs, check the following and replace parts as necessary.
 If the fusing belt is damaged, replace it.
 If the gap between the fusing stripper plate and fusing belt is wider than normal,
replace the fusing unit.
Note: The fusing stripper plate cannot be replaced individually (it can only be attached and
precision-adjusted at the factory).
 If the pressure roller is damaged, replace it.
 If the gap between the pressure roller stripper plate and pressure roller is wider
than normal, replace the pressure roller stripper plate.
