Technical Bulletin PAGE: 3/8
Reissued:28-Mar-14
Model: Charis-C1 (Office/Pro)
Date: 30-Jan-14
No: RD135094b
Solution
A Mylar sheet (p/n: D1364668) was added to the duplex entrance guide plate to prevent the
leading edge of curled paper from getting caught by the hole.
Model: Charis-C1 (D135/D136/D137/D138)
NOTE
Machines with the following S/N have a modified duplex entrance unit with the Mylar pre-
attached at the factory to prevent Jam33.
Added part number
Description
Q’ty
D1364578
DUPLEX SUB-UNIT:ENTRANCE:GATE PAWL:ASS'Y
1
D1364668
SHEET:DUPLEX:ENTRANCE:RIGHT UPPER
1
Model
S/N
Model
S/N
D135-17
E233CA00287
D136-17
E243CA00042
D135-21
E233CB20001
D136-21
E243CB20001
D135-27
E233CA30071
D136-27
E243CA30015
D135-29
E233CA50014
D136-29
E243CA50011
Newly added Mylar
D1364668 SHEET: DUPLEX: ENTRANCE: RIGHT UPPER
