Ricoh CH-C1 - Page 32

Technical Bulletin PAGE: 7/14
Reissued:15-Oct-13
Model: CH-C1
Date: 17-Sep-13
No.: RD135028b
5. Pull out the toner supply unit [A].
6. Remove the toner supply unit [A]. (screw x2)
7. Remove the filament tape from the faceplate [A].
