Technical Bulletin PAGE: 10/14
Reissued:15-Oct-13
Model: CH-C1
Date: 17-Sep-13
No.: RD135028b
13. Unlock the lever [A] and pull out the PCDU [B] from the machine.
14. Place the PCDU [A] on the PCU stand [B].
15. Remove the charge roller unit and place it on a clean, flat surface with the roller facing
up. (screw x2)
Place the charge unit on a flat surface.
