Ricoh CH-C1 - Page 438

Technical Bulletin PAGE: 2/10
Model: CH-C1 Office/Pro
Date: 26-May-14
No.: RD135120
3. At the rear side, remove the screw circled in the photo below from the stapler [A].
4. Push the stapler to the front side of the finisher.
5. Remove the inner upper cover [A]. ( x 2)
6. Pull out the stapler unit [A].
