Technical Bulletin PAGE: 2/2
Model: CH-C1 Office/Pro
Date: 26-May-14
No.: RD135121
3. Remove the left tandem tray [A] (M3 x 8 x 2 on the left side, M3 x 10 x 3 on the right side).
4. Remove the front cover [A] from the left tandem tray ( x 2).
5. Pull out the right tandem tray [A] and remove the screws (TCRU/ORU x2).
