Technical Bulletin PAGE: 2/4
Model: CH-C1
Date: 26-Mar-14
No: RD135128
SOLUTION
Production line:
A spring inside the coupling was modified to prevent incomplete engagement of the pin
and coupling.
Cut-in S/N
Model
S/N
Model
S/N
D135-17
E233CC00047
D136-17
E243CC00005
D135-21
E233CC20001
D136-21
E243CC20001
D135-27
E233CC30001
D136-27
E243CC30011
D135-29
E233CC50001
D136-29
E243CC50001
Model
S/N
Model
S/N
D137-17
E253CC00034
D138-17
E263CC00001
D137-21
E253CC20001
D138-21
E263CC20001
D137-27
E253CC30001
D138-27
E263CC30011
D137-29
E253CC50001
D138-29
E264C150001
In the field:
Procure and attach the following spacer to the side plate on the mainframe. This will
prevent the feeler on the end fence from retracting.
See the following pages for the procedure on how to attach the spacer.
P/N
Description
Q’ty
D1369504
SPACER:TANDEM
1
