Technical Bulletin PAGE: 3/17
Model: CH-C1 Pro
Date: 2-Jun-14
No.: RD135134
No
Old P/N
New P/N
Description
Q’ty
Int
Group
Top: OLD
Bottom: NEW
8
D1367096
D1367163
SHAFT:GATE:
REVERSE EXIT
1
X/X
B
Note that the flaps are NOT included with
the shaft. Flaps are attached in this photo
to make the difference more noticeable.
9
D1367110
D1357117
GUIDE PLATE:
EXIT:LEFT
LOWER:ASS'Y
1
X/X
B
Mylar sheet is black on some old units.
10
D1367181
D1357111
ROLLER:EXIT:
MIDDLE:ASS'Y
1
X/X
B
11
D1367183
D1357112
ROLLER:
REVERSE:EXIT:
ASS'Y
1
X/X
B
12
-
D1367077
STAY:PAPER
EXIT UNIT:
RIGHT LOWER
1
X/X
C
