Technical Bulletin PAGE: 2/19
Reissued: 19-Mar-16
Model: Copy Tray Type M2
Date: 4-Oct-13
No.: RD135030e
Copy Tray Type M2 (D744)
Component Check
Check the accessories and their quantities against this list.
No.
Description
Q'ty
1.
COPY TRAY:EXIT:ASS'Y
1
2.
BRACKET:COOLING UNIT:ASS'Y
1
3.
COOLING UNIT:ASS'Y
1
4.
CLAMP:LWC-3A
1
5.
TAPPING SCREW:4X8
2
6.
TAPPING SCREW:ROUND POINT:3X6
2
7.
SCREW:M4X20
4
8.
LEVER
1
9.
BRACKET:SENSOR:PAPER VOLUME SENSOR
1
10.
SPRING PLATE:SENSOR:EXIT
1
11.
PHOTOINTERRUPTOR:GP1A173LCS2F
1
12.
CLAMPS:WES-0507
1
13.
SHEET:COPY TRAY:EXIT
 This part was replaced with the new part indexed #22 since
Jun, 2014.
1  0
14.
DECAL:CAUTION:EXIT
1
15.
TAPPING SCREW - M3X6
1
16.
TAPPING SCREW:3X8
2
17.
CONNECTOR:2-292246-2 (for use with D135/D136 only)
1
18.
CLAMP:LWSM-0511A
1
19.
PCB:OKB
1
20.
HARNESS:EXIT:TRAY:COOLING UNIT:OKB
1
21.
TAPPING SCREW:
1
22
SHEET: GUIDE PLATE: EXIT
 This part was modified in Jun, 2014, previously indexed
#13.
0  2
23
GUIDE: COPY TRAY: EXIT
 New part added since Jun, 2014.
0  1
24
SHEET: COPY TRAY: EXIT
 New part added since Jun, 2014.
0  1
