SP Tables
M047 3-32 SM Appendix
5803
Input check
Displays signals received from sensors and switches.
NOTE: SP Modes other than those listed in this table, are not used in the
machine.
Operation Panel Component Name
5803 1 Cover Info
Front and rear cover safety switches
0: Close, 1: Open
Front door open: bit 0
Paper exit door: bit 1 and 0
Rear cover: bit 2, 1 and 0
5803 2 Main Motor Lock Main Motor Lock
5803 3 Polygon Motor Lock Polygon Motor Lock
5803 4 Fan High Fusing fan; 0: Stop, 1: Lock
5803 5 Fan Lock Fusing fan; 0: Stop, 1: Lock
5803 6 PSU Fan Lock PSU fan; 0: Stop, 1: Lock
5803 7 Destination 0: NA model, 1: EU model
5803 8 AIO Unit Set 0: Not set, 1: Set
5803 9 Fuser Temp Error 0: Normal, 1: Error
5803 10 Toner End Sensor 0: Not end, 1: End
5803 11 Paper Full Sensor 0: Not full, 1: Full
5803 12 Carry Sensor
Paper exit sensor;
0: Paper not detected, 1: Paper detected
5803 13 Regist Sensor 0: Paper not detected, 1: Paper detected
5803 14 Exit Sensor
Fusing exit sensor;
0: Paper not detected, 1: Paper detected
To Next Page
