4.11 IMAGE ADJUSTMENT
4.11.1 REGISTRATION ADJUSTMENT
The registration is adjusted using the user mode; "Maintenance-Registration.” For details,
see the Printer Reference operation manual.
4.11.2 PARALLELOGRAM IMAGE ADJUSTMENT
 Use the scanner positioning pin (P/N: A0069104) for the adjustment.
 Do the following procedure if a parallelogram is printed while adjusting the printing
registration using a trimming pattern.
